Rinnai S20 User Manual

Rinnai 15 Split Solar OIM
Stainless Steel Gas Boosted Cylinders
250 315
Cylinder height 1700 2090
PTR / hot water to booster 1490 1880
Gas booster ue outlet 1345 1735
Gas supply and hot water outlet 880 1270
Flow line to collectors 650 650
Solar return 300 300
Cold water inlet 210 210
Cylinder diameter 600 600
System depth 795 795
Weight empty (kg) 56 68
PTR VALVE
GAS SUPPY AND
HOT WATER OUTLET
GAS BOOSTER FLUE OUTLET
CYLINDER HEIGHT
CYLINDER DIAMETER
SYSTEM DEPTH
FLOW LINE TO COLLECTORS SOLAR RETURN
COLD WATER INLET
SPECIFICATIONS

Rinnai S20 Specifications

General

Brand	Rinnai
Model	S20
Category	Water System
Language	English
