Flame Rod, Electrode and Sight Grass Removal
Ensure unit is isolated from power and gas supply.
1. Remove (3) screws shown with red circles.
2. Unplug yellow flame rod wire.
3. Unplug black electrode cable and green wire to casing.
4. Remove sight grass plate, flame rods and electrode from unit.
5. Before reassembly install new electrode gasket, never reuse.
The flame rod has a special coating. Cleaning the flame rod may remove this coating leading to code 12’s.
Electrode gasket
Flame rod Electrode
Electrode gap is 3.5 mm.
