Rinstrum C510 User Manual

Name Address Type R W Description
User String 3 0092
H
string A A User readable/writable string 3
User String 4 0093
H
string A A User readable/writable string 4
User String 5 0094
H
string A A User readable/writable string 5
Display Top Left 00B0
H
string N A Write to the top left of the screen
Display Annunciators 00B2
H
uint32 N A Write the annunciators to display. Bit
0: Zero
1: Motion
2: Gross
3: Net
4: Zero band
5: Held
6: Spare 1
7: Range 1
8: Range 2
9: Range 3
10: Check under 2
11: Check under 1
12: Check pass
13: Check over 1
14: Check over 2
15: IO 1
16: IO 2
17: IO 3
18: IO 4
19: IO 5
20: IO 6
21: IO 7
22: IO 8
23: Spare 2
24: Spare 3
Display Units 00B3
H
uint8 N A Write the units to display.
0 for none
1 for g
2 for kg
3 for t
4 for lb
5 for oz
8 for spare
16 for all.
Auto Annunciators 00B6
H
uint8 N A Update the annunciators automatically. 0
for off, 1 for on.
Secondary Gross/Net Weight 00C0
H
weight A N Displayed weight in secondary units
Secondary Tare Weight 00C1
H
weight A N Tare weight in secondary units
Tertiary Gross Weight 00C2
H
weight A N Gross weight in tertiary units
Tertiary Net Weight 00C3
H
weight A N Net weight in tertiary units
Tertiary Gross/Net Weight 00C4
H
weight A N Displayed weight in tertiary units
Tertiary Tare Weight 00C5
H
weight A N Tare weight in tertiary units
Full passcode 00D0
H
uint32 F F Full passcode
Safe passcode 00D1
H
uint32 S S Safe passcode
Calibration weight 0100
H
int32 A A Weight used for span calibration or
linearisation
Zero calibration 0102
H
execute N F Calibrate the scale zero
81 C500-600-2.0.3
