Name Address Type R W Description
Span calibration 0103
H
execute N F Calibrate the scale span. Ensure that the
calibration weight is set first.
Edit linearisation 0104
H
execute N F Edit a linearisation point, takes the
linearisation point as an argument. Ensure
that the calibration weight is set first.
Clear linearisation 0105
H
execute N F Clear a linearisation point, takes the
linearisation point to be cleared as an
argument
Direct zero calibration 0106
H
execute N F Direct mV/V zero calibration, takes the
mV/V value * 10000 at zero as an
argument (1.0000 mV/V should be entered
as 10000).
Direct span calibration 0107
H
execute N F Direct mV/V span calibration, takes the
mV/V value * 10000 at full scale relative
to zero as an argument (1.0000 mV/V
should be entered as 10000).
Zero mV/V value 0111
H
int32 A N mV/V value of the zero point * 10000.
Span weight 0112
H
int32 A N Weight used for the span calibration.
Span mV/V value 0113
H
int32 A N mV/V value of the span point relative to
the zero point * 10000.
Linearisation correction
weight
0114
H
execute A A Execute with the linearisation point
number (0 - 9) to get the correction weight
at that linearisation point.
Linearisation percentage 0115
H
execute A A Execute with the linearisation point
number (0 - 9) to get the percentage value
between zero and span for that
linearisation point.
Number of decimal places 0128
H
uint8 A F Set the number of decimal places of the
scale.
Scale units 0129
H
uint8 A F Values:
0 is none
1 is grams
2 is kilograms
3 is pounds
4 is tonnes
5 is ounces
6 is user.
Current Time/Date 0150
H
string A N Read this register to get current
instrument date/time (e.g. 10/12/2016
18:30:10).
Date Format 0151
H
uint8 A A Write 0 for DD.MM.YY
1 for DD.MM.YYYY
2 for MM.DD.YY
3 for MM.DD.YYYY
4 for YY.MM.DD
5 for YYYY.MM.DD
RTC Day 0152
H
uint8 A A Read/Write current day (1..31)
RTC Month 0153
H
uint8 A A Read/Write current month (1..12)
RTC Year 0154
H
uint16 A A Read/Write current year (2000..2099))
RTC Hour 0155
H
uint8 A A Read/Write current hour (0..23)
RTC Minute 0156
H
uint8 A A Read/Write current minute (0..59)
82 C500-600-2.0.3
