Installation and Programming Manual
3-78
ACCESSORIES: ADD/DELETE MODULE (cont’d)
Quick Key Item Default Explanation
ADD/DELETE
MODULE (cont’d)
---
7 1 3 Utility Output Module NONE at this display:
using either the UP- or DOWN-arrow keys, position
the cursor over the Utility Output’s I.D. number for
which you wish to assign (or delete) such a unit
the first UO must be assigned to the first I.D. number,
which is “1”
be sure that the UO’s physical I.D. number has been
“DIP-switch” programmed, accordingly, per the
instructions on page 2-5
with the cursor positioned over the “TYPE” field,
press the [STAY] key to toggle between and choose
among the four selections given:
NONE
UO04 (a 4-Output Relay-Type Unit)
UO08 (an 8-Output Solid-State Type Unit)
XO08 (the X-10 Transmitting Module)
once the proper selection is made, press
[ENTER] to store your choice and to repeat
the process for any other Utility Output Modules
in the system; up to the system’s maximum of 8
once done, press [.] to return to the previous
programming level
PLEASE NOTE
:
the following display will appear if a Utility Output
Module is found and “NONE” has been selected; if so:
press [ENTER] to return to the prior display
OR
press [STAY] to select “Y”, and press [ENTER] to
confirm the delete
UTIL OUTPUT:
ID=1 TYPE=NONE
..DELETE..
RE YOU SURE? N
INSTALLER PROG:
7)ACCESSORIES ↓
