Installation and Programming Manual 1-9
T
T
e
e
c
c
h
h
n
n
i
i
c
c
a
a
l
l
D
D
a
a
t
t
a
a
Control Panel
Input Power: 16.5 Volts AC @ 40 Volt-Amps (VA) (via transformer)
Rechargeable Standby Battery: 12 Volts 6 Amp-Hours (AH), typical
Power Outputs
Auxiliary Power:
Switched Auxiliary:
Bell/LS (External) Sounder Output:
12 Volts DC @ 600 mA, maximum
12 Volts DC @ 160 mA, max. for UL installations
12 Volts DC @ 250 mA, maximum **
12 Volts DC @ 80 mA, max. for UL installations
12 Volts DC @ 900 mA, maximum
** included in the 600 mA of Auxiliary Power
Programmable Voltage (Utility) Output: Open-Collector Active Pull-Down, 70 mA, maximum
Cabinet Dimensions: 30.5cm x 29.7cm x 8.4cm
12.0 in x 11.7 in x 3.3 in
Weight: 3.5 kg / 7.7 lbs.
Main Board Dimensions: 20 cm x 11.5 cm x 3.1 cm
7.9 in x 4.8 in x 1.2 in
F1 responsible for:
Auxiliary Power:
Switched Auxiliary:
Keypad Power:
1.0 A
F2 responsible for:
Bell/LS Power:
1.0 A
Fuses:
F3 responsible for
:
Battery Power:
3.0 A
Keypads
Current Consumption: 8 LED: 75 mA, maximum
16 LED: 75 mA, maximum
KCL: 100 mA, maximum
Control Panel Connection: 4-wire BUS, up to 1000 ft (300m) from panel
Dimensions: 15cm x 11.6cm x 3cm
5.9 in x 4.6 in x 1.2 in
Weight: 250 gr
0.55 lbs.
Zone Expansion Module: 8-Zone
Current Consumption: 25 mA, typical / 34 mA, maximum
Control Panel Connection: 4-wire BUS, up to 1000 ft (300m) from panel
Dimensions: 10.5cm x 6.6cm x 1.8cm
4.1 in x 2.6 in x 0.7 in
Utility Output Expansion Module: 4-Output
Current Consumption: 25 mA, typical / 140 mA, maximum
Contacts: 4 Form C (SPDT) Relays
contact rating: 5 A / 24 Volts DC
Control Panel Connection: 4-wire BUS, up to 1000 ft (300m) from panel
Dimensions: 10.5cm x 6.6cm x 2.2cm
4.1 in x 2.6 in x 0.87 in
Utility Output Expansion Module: 8-Output
Current Consumption: 25 mA, typical / 30 mA, maximum
Contacts: Open-Collector, Active Pull-Down, 70 mA, maximum
Control Panel Connection: 4-wire BUS, up to 1000 ft (300m) from panel
Dimensions: 10.5cm x 6.6cm x 1.8cm
6.5 in x 2.6 in x 0.7 in
