Installation and Programming Manual
1-10
Power Supply Expansion Module
Input Power: 16.5 Volts AC @ 40 VA (via transformer)
Rechargeable Standby Battery: 12 Volts 6 Amp-Hours (AH), typical
Power Outputs
Auxiliary Power:
Bell/LS (External) Sounder Output:
12 Volts DC @ 600 mA, maximum
12 Volts DC @ 900 mA, maximum
Control Panel Connection: 4-wire BUS, up to 1000 ft (300m) from panel
Dimensions: 9.0cm x 9.0cm x 6.7cm
3.5 in x 3.5 in x 2.6 in
Event Log Expansion Module
Current Consumption: 25 mA, typical / 29 mA, maximum
Control Panel Connection: 4-wire BUS, up to 1000 ft (300m) from panel
Dimensions: 10.5cm x 6.6cm x 1.8cm
4.1 in x 2.6 in x 0.7 in
Printer Module
Current Consumption: 7mA, typical / 10mA, maximum
Control Panel Connection: 4-wire BUS, up to 1000 ft (300m) from panel
Dimensions: 6.2cm x 5.3cm x 1.6cm
2.44 in x 2.08 in x 0.6 in
X-10 Transmitter Module
Current Consumption: 25 mA, typical / 29 mA, maximum
Control Panel Connection: 4-wire BUS, up to 1000 ft (300m) from panel
Dimensions: 10.5cm x 6.6cm x 1.8cm
4.1 in x 2.6 in x 0.7 in
Table 1-3
