Installation and Programming Manual
3-2
P
P
r
r
e
e
p
p
a
a
r
r
i
i
n
n
g
g
Y
Y
o
o
u
u
r
r
P
P
r
r
o
o
-
-
2
2
4
4
f
f
o
o
r
r
I
I
n
n
s
s
t
t
a
a
l
l
l
l
e
e
r
r
P
P
r
r
o
o
g
g
r
r
a
a
m
m
m
m
i
i
n
n
g
g
There are three “Getting Started” options when learning how to program your Pro-24.
OPTION 1: You wish to program a new Pro-24
for the first time.
OPTION 2: You wish to restore all factory defaults to an already-programmed Pro-24
.
OPTION 3: You wish to modify the configuration of an existing Pro-24
. For this, proceed directly to one of the
following pages:
Description and Use of the LCD Keypad page 3-5
Installer Programming Tutorial page 3-10
Actual Programming page 3-14
For Options 1 and 2
A. Preparing the LCD Keypad:
1- Remove all Power from Your Pro-24
a) If your Pro-24 has NOT been wired to an LCD Keypad
, remove all power (AC and Standby Battery) if
present, and skip to Step 2
.
b) If your Pro-24 and at least one LCD Keypad have already been physically installed and/or wired
together, remove all power (AC and Standby Battery) if present, and skip to Step 3.
2- Wire a single LCD Keypad to the Pro-24’s Main Board
a) If required, add additional wiring to the keypad, by using no more than 1000 feet of the appropriate
wire.
3- If necessary, check the LCD Keypad’s Physical I.D. Number
If the LCD Keypad(s) have already been given an I.D. number, skip to Step 5. Otherwise, separate the
keypad’s cover from its base, locate the bank of four DIP switches and make sure the keypad is given the
I.D. of “01”, by verifying that all four switches are in the down (OFF) position
4- Reassemble the Keypad
Carefully replace the keypad’s printed circuit board in its cover housing
join the unit’s cover and base by first hooking the tops together and then snapping the bottoms in place
5- Setting the Keypad’s Tamper Switch
If the keypad is not yet mounted, locate its rear-mounted tamper “plunger” and set its action as follows:
a) if, during programming, the keypad is to be wall-mounted, be sure the slot in the plunger is vertically-
oriented, and reinstall the keypad
b) otherwise, for bench, table-top, or “hand-held” programming, turn the plunger so that its slot is
horizontally-oriented
B. Preparing the Panel: (refer to Figure 2-7 on page 2-12)
6- Check the Condition of the Pro-24’s J2 (DEFAULT) Jumper
Option 1
: If you are Programming a New Pro-24:
a) Be sure the jumper is NOT placed over its corresponding pins
. You may wish to place it on one of the
pins for safekeeping.
b) Proceed to Step 7.
Option 2
: If you are Restoring Factory Defaults to an Pro-24:
a) Place the jumper in the DEFAULT position so it covers BOTH of the corresponding pins
.
b) Proceed to Step 7.
7- Apply Power to the System
Do so by plugging in the AC transformer, and/or connecting the Standby Battery to the RED and BLACK
flying leads. After a moment, the keypad will display:
RISCO
Please Wait ...
To Next Page
Loading...
