Installation and Programming Manual 3-11
EXAMPLE 3: Adding A Zone Expansion Module
1- Press the [.] key until you are returned to your
previous selection in the “HOME” column.
2- Read this step first before pressing any keys.
To gain entry into Adding Expansion Modules
category, you can either press the DOWN-
arrow twice to access the following display,
and then press [ENTER]. If so, go directly to
Step 3…
OR
You can skip this display and the need for
Pressing [ENTER] and go directly to Step 14 by
simply pressing the “Quick Key” [7].
3- At this display:
press [ENTER] to derive the next display.
4-
Read this step first before pressing any keys.
To add a Zone Expansion Module
, you
can either press the DOWN-arrow once to
access the following display,
and then press [ENTER]. If so, go directly to
Step 4…
OR
you can skip this display and the need for
pressing [ENTER] and go directly to Step 16 by
simply pressing the “Quick Key” [2].
5- From this display:
press either the [STAY] or [ARM] key until
the proper Zone Expansion Module appears.
Choose among the following:
ZE08 (adds 8 Hardwired Zones)
ZE16 (adds 16 Hardwired Zones)
WZ08 (adds 8 Wireless Zones)
WZ16 (adds 16 Wireless Zones)
which, when installed, would have to be “DIP
switch” set with the physical I.D. of “1”.
6- When done, press the [.] key, as required, to
return to the “HOME” column.
7- Read this step first before pressing any keys.
You can Exit from Installer Programming
by
using the DOWN-arrow key to scroll to this
display:
and pressing [ENTER]…
OR
by pressing the “Quick Key” [0]. In either
case, the following display will appear:
8- At this point, you may either
press [ENTER] to save the changes you
made; they will be stored in the Pro-24’s
configuration until such time as they should
be modified or reset
OR
for purposes of this tutorial, any changes
you made can be discarded by selecting
“N”, using either the [STAY] or [ARM] key,
followed by pressing [ENTER].
In either case, after a few moments, the
Pro-24 will return to its normal (user)
display.
NOTE: The (00:01) in Step 4 of Example 1 is a factory device “address” and has no bearing on your programming.
Keypad Timeout
If, after 15 minutes, no entry is made to a keypad placed in the Installer Programming, it will produce an audible
reminder consisting of several beeps in rapid succession, along with this display:
Pressing any key will stop the beeps. To re-enter Installer Programming, you’ll have to key in your Installer Code,
and press [ENTER].
INSTALLER PROG:
5)DIALER ¤
CCESSORIES:
1)ADD/DEL MDL ↓
ZONE EXPANDER:
ID=1 TYPE=NONE
DO YOU WANT TO
SAVE THE DATA? Y
INSTALLER PROG:
7)ACCESSORIES ¤
DD A MODULE:
2)ZONE EXP. ¤
DD A MODULE:
1)KEYPAD ↓
INSTALLER PROG:
0)EXIT PROGRAM ↑
TIMEOUT
HIT ANY KEY
