UTILITY OUTPUT (cont’d)
Quick Key Pattern of Operation: Default Explanation
choose among the following patterns for the
selected utility output.
1 Pulse N/C 20
seconds
the Utility Output will always be activated (N/C)
before being triggered
when triggered it will de-activate
for the
Pulse Duration
specified below, then re-
activate automatically
if selected, press [ENTER] and choose the
desired Pulse Duration
, between 01-90
seconds; press [ENTER]
proceed to Choosing a Label for the UO, below
2 Latch N/C --- the Utility Output will always be activated (N/C)
before being triggered
when triggered it will de-activate
and remain so
(latch) until the operation restored.
press [ENTER]
proceed to Choosing a Label for the UO, below
3 Pulse N/O
20 seconds
the Utility Output will always be de-activated
(N/O) before being triggered
when triggered it will activate
for the
Pulse Duration
specified below, then de-
activate automatically
if selected, press [ENTER] and choose the
desired Pulse Duration
, between 01-90
seconds; press [ENTER]
proceed to Choosing a Label for the UO, below
4 Latch N/O --- the Utility Output will always be de-activated
(N/O) before being triggered
when triggered it will activate
and remain so
(latch) until the operation restored.
press [ENTER]
proceed to Choosing a Label for the UO, below
LABEL FOR
UTILITY
OUTPUT
--- for the user’s convenience (see page 3-5), you
may create and/or edit a ten character
description for the selected Utility Output
to do so, follow the instructions on keypad
labeling, found in the examples on pages 3-21
and 3-31
INSTALLER PROG:
3) UO ↓
To Next Page
