3.2.1.6 Low Current Noise Cutoff.
This screen allows the user to set Low noise current cutoff in mA.
screen. Touching radio button in front of particular option will
Two options, 0 MILLI-AMPERE & 30 MILLI-AMPERE are displayed on
select that option.
Touch on “ key” will conrm the setting.
and will return to previous menu.
Touching the “ key” will keep the old selected setting
LINE-NEUTRAL VOLTAGE
VL2
VL2VL2
LINE-NEUTRAL VOLTAGE
VL2
VL2VL2
LINE-NEUTRAL VOLTAGE
VL2
VL2VL2
CT SECONDARY
5 AMPERE
1 AMPERE
LINE-NEUTRAL VOLTAGE
VL2
VL2VL2
LINE-NEUTRAL VOLTAGE
VL2
VL2VL2
LINE-NEUTRAL VOLTAGE
VL2
VL2VL2
LOW CURRENT NOISE CUTOFF
0 MILLI-AMPERE
30 MILLI-AMPERE
OK
BACK
BACK
OK
OK
While in Auto-scrolling mode, touch sense for entire screen will be disabled except for the
top right most corner where “A” symbol would be displayed stating that meter is in Auto-
scroll mode.
Touching on “A” will show two options “ON” and “OFF”. Touching on “ON” will continue
auto scrolling & touching on “OFF” will stop auto-scrolling & return to normal mode.
BACK
OK
OK
depending as per the user’s requirement .
This setting is applicable for all types of energy.
3.2.1.7 ENERGY RESOLUTION
This screen enable user to set energy in terms of Wh / kWh / MWh on Rs485 Output
screen. Touching radio button in front of particular option will
Three options: WATT, KILO-WATT & MEGA-WATT are displayed on
select that option.
Touch on “ key” will conrm the setting.
and will return to previous menu.
Touching the “ key” will keep the old selected setting
LINE-NEUTRAL VOLTAGE
VL2
VL2VL2
LINE-NEUTRAL VOLTAGE
VL2
VL2VL2
LINE-NEUTRAL VOLTAGE
VL2
VL2VL2
CT SECONDARY
5 AMPERE
1 AMPERE
LINE-NEUTRAL VOLTAGE
VL2
VL2VL2
LINE-NEUTRAL VOLTAGE
VL2
VL2VL2
LINE-NEUTRAL VOLTAGE
VL2
VL2VL2
ENERGY ON RS485
WATT (W)
KILO-WATT (KW)
MEGA-WATT (MW)
OK
BACK
Note : Default value is set to ‘WATT’ i.e. Energy on Modbus will be in
terms of Wh/VArh/VAh respectively.
