Response: System Type ( 3phase 4 wire = 3 )
Device Address
Function Code
Byte Count
Data Register1 High Byte
01 (Hex)
03 (Hex)
04 (Hex)
40 (Hex)
Data Register1Low Byte
40 (Hex)
Data Register2 High Byte
00 (Hex)
00(Hex)
Data Register2 Low Byte
EE (Hex)
CRC Low
CRC High 27 (Hex)
Byte Count : Total number of data bytes received.
Data register 1 High Byte : Most signicant 8 bits of Data register 1 of the parameter requested.
Data register 1 Low Byte : Least signicant 8 bits of Data register 1 of the parameter requested.
Data register 2 High Byte : Most signicant 8 bits of Data register 2 of the parameter requested.
(Note : Two consecutive 16 bit register represent one parameter.)
Data register 2 Low Byte : Least signicant 8 bits of Data register 2 of the parameter requested.
Start Address High : Most signicant 8 bits of starting address of the parameter requested.
Start Address low :Least signicant 8 bits of starting address of the parameter requested.
Number of register Hi : Most signicant 8 bits of Number of registers requested.
Number of register Lo : Least signicant 8 bits of Number of registers requested.
(Note : Two consecutive 16 bit register represent one parameter.)
