This chapter introduces apperance of the gateway and show how to setup your gateway and connect it
to a cloud LoRaWAN server.
2.1 Get to know about your gateway
RisingHF RHF2S208 LoRaWAN gateway integrates a high performance high reliabitliy ARM cortex A53,
1 or 2xSX1301 LoRa core processor, a 4G LTE module, a GPS module, a WiFi module, temperature
monitor, RTC, and power management unit. The RHF2S208Bxx series would have a internal battery for
backup which could support over 5 hr duration without external power. Rather than logging into the
gateway and doing operation with command in the linux environment, a web-based utility is built in
which help customer use the device much easier.
There are 4 antenna ports, a external power input port, a RJ45 port, and a USB debug port for the
device.
ANT1 ANT3 ANT4 ANT5 :
The RHF2S208 gateway have 4 antenna ports. ANT1 is for LoRa antenna (ANT2 is not used at this
moment). ANT3 is for GPS antenna. ANT4 is for WiFi Antenna. ANT5 is for LTE Antenna.
Power: External power supply input port, DC12 to 28V.
RJ45: RJ45 port, ethernet and PoE power injector.
USB: USB port for debug.
To Next Page
