RADIO CONNECTORS
-----------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------
Ritron RCCR Clean Cab User Manual 12
RCCR Connectors – Rear Panel
Remote Control Head (19-Pin Female) Rear Handset (6-Pin)
A Mic Audio H No Connection P No Connection A Mic Audio
B No
Connection J Vcc R No Connection B Mic Ground
C No Connection K Not Used S RXD 232 C PTT
D No
Connection L Ground T TXD 232 D PTT Ground
E Mic Ground M Speaker (-) U Handset Ground E Receive Audio
F Not Used N Speaker (+) V Handset Audio F Not Used
G No
Connection
A
B
C
D
E
FG
J
K
L
M
NP
R
ST
U
A
B
C
D
E
F
V
5 4 3 2 1
9
8 7 6
15 14 13 12 11 10 9
8
7654321
Accessory / Program Connector (DB15)
Data Connector (DB9)
1 TD 6 MONITOR 11 GROUND 1 No Connection 6 DSR
2 CD 7 SPAREIN 12 RD 2 RD 7 RTS
3 ACC_T
X 8 SPAREOUT 13 DTR 3 TD 8 CTS
4 EXPTT 9 DISC_OUT 14 RTS 4 No Connection 9 No Connection
5 MUT
E 10 ACC_AUD 15 CTS 5 Ground
F
H
