RADIO CONNECTORS
-----------------------------------------------------------------------------------------
---------------------------------------------------------------------------------------------------------------
Ritron RCCR Clean Cab User Manual 14
RCCR Connectors – Remote Head
A
M
L
K
J
H G
E
D
C
B
PN
U
TS
R
A
B
C
D
E
F
V
F
Remote Control Head (19-Pin Male)
Remote Head Handset (6-Pin)
A Mic Audio H No Connection P No Connection A Mic Audio
B No Connection J Vcc R No Connection B Mic Ground
C No
Connection K Not Used S RXD 232 C PTT
D No Connection L Ground T TXD 232 D PTT Ground
E Mic Ground M
Speaker (-) U Handset Ground E Receive Audio
F Not Used N Speaker (+) V Handset Audio F Not Used
G No
Connection
