3.3 Functions
The functions of the RITTAL CMC-TC Master are focused on the management of up to 10
Processing Units and of the components connected to these, such as sensors, access
controls, and climate control components. These functions are administered and controlled
by means of the protocols listed below:
• Terminal programs
• through serial interface RS232: e.g. Hyperterminal
• in Ethernet network: e.g. through TELNET (Tera Term), SSH
• SNMP V1.0, compatible with the usual management systems
• HTTPS
• TFTP
Optional:
• WebCam support (USB version) up to 2 units (see Appendix A 1 Scope of supply
accessories – CMC-TC Master)
See Appendix C 1 Functional diagram
See Appendix I 1 Operation of CMC-TC Master by browser
The more detailed description of the software functions is given in Appendix J 1 Software
functions, and also the explanation of the layout of the table structure as follows.
Item:
Call: Telnet, Hyperterminal
To-Do Software function
Value
range
Factory setting
Hyperterminal Telnet Browser
0 Login
0.1
Query
User name
see table below.



0.2
Query
Password
see table below.



1 Network c
onfiguration
1
1.1.1
Setting
IP Address
192.168.30.100



2
1.1.2
Setting
IP Subnetmask
255.255.255.0



3
1.1.3
Setting
IP Router
0.0.0.0



For complete list, see Appendix J 1 Software functions
Function is supported
by …
Position
Call of menu
items in ...
Possible action
Description of software functions
Settable value range
Default
ex works
