11 Technical specifications
11
46 Rittal Liquid Cooling Package
11 Technical specifications
11.1 LCP Rack DX/LCP Inline DX
Technical specifications
Description/Model No. LCP Rack DX / 3311.410 (1000 mm depth)
Description/Model No. LCP Rack DX / 3311.420 (1200 mm depth)
Description/Model No. LCP Inline DX / 3311.430 (1000 mm depth)
Description/Model No. LCP Inline DX / 3311.440 (1200 mm depth)
Dimensions and weight
Dimensions width x height x depth [mm] 300 x 2000 x 1000 (3311.410/430) or 1200 (3311.420/440)
U height 42
Weight, max. [kg] 201
Electrical connection
Type of electrical connection Connection clamp
Rated voltage [V, Hz] 380…480 V ±10 %, 3~, N, PE, 50/60 Hz
Rated current [A] 7.5
Startup current [A] 11
Pre-fuse T [A] 20
Duty cycle [%] 100
Cooling output
Nominal cooling capacity EN 14511 [kW] L35 L35 9.0
L35 L30 12.0
Total power input [kW] L35 L35 4.0
L35 L30 4.0
Energy Efficieny Ratio (EER) L35 L35 3.0
Air throughput, max. [m
3
/h] 4,800
Cooling circuit
Coolant/Fill volume [kg] R410A/see tab. 23 "Total refrigerant charge"
Max. allowable pressure [bar] PS HP: 42
PS LP: 30
Connection diameter refrigerant pipes [mm] See tab. 24 "Refrigerant pipes"
External diameter of coolant lines [mm] See tab. 24 "Refrigerant pipes" (1 mm wall thickness)
Other information
Storage temperatures [°C] -20…+50
Temperature range [°C] +15…+35 (indoor)
IP protection category IEC 60529 IP 20 (indoor)
Tab. 17: Technical specifications LCP DX
