Riva RC3500 - Environment Condition

19
www.rivatech.de
(S/W Day & Night or
Removal IR Cut Filter)
Electrical Characteristics
Video Output
1Vp-p, 75Ω
Audio Input
Linein, 1.43Vp-p(Min 1.35Vp-p, max 1.49 Vp-p), 39
KΩ
Audio Output
Lineout, 46mW Power, 16 Ω
Sensor(D/I)
TTL level 4.5V threshold, Max 50mA
Alarm(D/O)
Max 500mA@24VAC or 1A@12VDC
Power Source
DC 12V / PoE IEEE802.3af (Class 0)
Power Consumption
(Approx.)
3.84W (DC 12V) /
4.56W (PoE)
7.10W (DC 12V) /
7.58W (PoE)
Video
Compression Format
H.264, MPEG-4, MJPEG Selectable per Stream
Number of Streams
Dual Stream, Configurable
Resolution
D1, 4CIF, 2CIF, VGA, QVG, CIF, QCIF
Compression FPS
25/30 fps@D1 (PAL/NTSC)
Deinterlacing
Supported (DSP)
Motion Detection
Supported
OSD
Supported (DSP)
Burnt-in Text (Digital)
Supported (DSP)
Output
1 Loop Out (BNC connector)
Audio
Input/output
1/1 channel
Compression Format
G.711
Function
Digital Input/output
1/1 channel
RS-485
Supported
Network
10/100 Base-T
Power over Ethernet
Supported
Protocol
TCP/IP, UDP/IP, HTTP, RTSP, RTCP, RTP/UDP,
RTP/TCP,
SNTP, mDNS, UPnP, SMTP, SOCK, IGMP, DHCP,
FTP, DDNS, SSL v2/v3, IEEE 802.1X, SSH, SNMP
v2/v3
SD Slot
Supported (MicroSD)
※ Micro SD Card is not included
Environment Condition
