RTC Series RTC Installation Guide
01A.04 26
5. Connect power source to the
camera and also a LAN cable.
Camera & Camera mount조립
Outdoor housing 조립
Camera mount plate 조립
Bolt 체결 Point
ODE-1000T_230 / 024
전원연결
ODE-1000T_PoE 전원연결
4. Connect LAN cable into the
internal power unit. And make sure
the high power PoE(PoE+) is used for
this installation.
5. Connect LAN cable to the camera.
4. Connect power source into the
terminal, located inside of the
housing. Make sure all cables are
correctly-connected to its
corresponding end. (+, - and
ground)
