XM670K
5. Parameters
Instructions for useRev.v. 01 | 9600- 0099 | © 2022 RIVACOLD srl
15
Parameter
Description
Values/Range
dot
Temperature alarm override time after door open alarm.
-
AOP
Alarm relay polarity: cL= normally closed. oP= normally open.
-
iAU
Auxiliary output independent of ON/OFF status: n= if the instrument is switched off,
the auxiliary output is also switched off. Y= the status of the auxiliary output is
independent of the ON/OFF status of the device.
-
5.1.6 Digital inputs
Parameter
Description
Values/Rang
e
i1P
Digital input 1 polarity. CL: the digital input is active when the contact is closed. OP:
The digital input is active when the contact is open.
cL, oP
i1F
Digital input 1 function. EAL= external alarm. bAL= block alarm. PAL= pressure switch
activation. dor= door open. dEF= defrosting activation. AUS= auxiliary activation. LiG=
light activation. OnF= ON/OFF switch. Htr= reversal of action type. FHU= not used. ES=
energy saving activation. Hdy= holiday function activation.
EAL, bAL, PAl,
dor, dEF,
AUS, LiG,
OnF, Htr,
FHU, ES, Hdy
d1d
Time interval before alarm signal: Time interval for calculating pressure switch tripping
before blocking when i1F=PAL. If I1F=EAL or bAL or dor, parameter d1d defines the
time interval before the alarm is signalled.
0...255 min
I2P
Digital input 2 polarity. CL: the digital input is active when the contact is closed. OP:
The digital input is active when the contact is open.
cL, oP
I2F
Digital input 2 function. EAL= external alarm. bAL= block alarm. PAL= pressure switch
activation. dor= door open. dEF= defrosting activation. AUS= auxiliary activation. LiG=
light activation. OnF= ON/OFF switch. Htr= reversal of action type. FHU= not used. ES=
energy saving activation. Hdy= holiday function activation.
EAL, bAL, PAl,
dor, dEF,
AUS, LiG,
OnF, Htr,
FHU, ES, Hdy
d2d
Time interval before alarm signal. Time interval for calculating pressure switch tripping
before blocking when i2F=PAL. If I2F=EAL or bAL or dor, parameter d2d defines the
time interval before the alarm is signalled.
0...255 min
i3P
Digital input 3 polarity. CL: the digital input is active when the contact is closed. OP:
The digital input is active when the contact is open.
cL, oP
i3F
Digital input 3 function. EAL= external alarm. bAL= block alarm. PAL= pressure switch
activation. dor= door open. dEF= defrosting activation. AUS= auxiliary activation. LiG=
light activation. OnF= ON/OFF switch. Htr= reversal of action type. FHU= not used. ES=
energy saving activation. Hdy= holiday function activation.
EAL, bAL, PAl,
dor, dEF,
AUS, LiG,
OnF, Htr,
FHU, ES, Hdy
d3d
Time interval before alarm signal. Time interval for calculating pressure switch tripping
before blocking when i3F=PAL. If I3F=EAL or bAL or dor, parameter d3d defines the
time interval before the alarm is signalled.
0...255 min
nPS
Maximum number of pressure switch interventions: number of activation at status during
time d#d before alarm signal(I#F= PAL). If the number of nPS interventions in time d#d
is reached, normal adjustment is restored by switching the instrument off and on again.
0...15
Odc
Compressor and fan status during open door. no= normal. Fan= Fans OFF. CPr=
Compressor OFF. F_C= Compressor and fans OFF.
-
rrd
Control restart after door open alarm doA. Adjustment starts again after the rrd delay
following the door open alarm.
0...255 min
5.1.7 Keyboard
Parameter
Description
Values/Range
bbc
Keyboard selection: 6 buttons
6bb
