6. Diagnostics and communication
Instructions for useRev.v. 01 | 9600- 0099 | © 2022 RIVACOLD srl
17
6. Diagnostics and communication
6.1 Alarms
6.1.1 List of alarm messages
Note: The reset of each alarm described below is automatic upon re-entry of the mentioned condition
Message
Reference
Meaning
How the machine behaves
PoN
-
Keyboard active
The keyboard is active, allowing access to
all parameters without any restrictions
PoF
-
Keyboard locked
The keyboard is locked, only allowing the
parameters of the Quick Access Menu to be
displayed
(dP1, dP2, L°t, H°t, dPr, dPd, dPF, rSE)
rst
-
Alarm reset
The alarm relay is reset
noP
Probe input
Probe not configured
The compressor enters a cycle of 15
min on (Con) and 15 min off (Cof)
P1
Probe input
Probe 1 error
The compressor enters a cycle of 15 min on
(Con) and 15 min off (Cof)
P2
Probe input
Probe 2 error
Defrosting lasts according to parameter
(MdF)
P3
Probe input
Probe 3 error
The machine works normally
HA
Temperature threshold
High temperature alarm
The machine works normally
LA
Temperature threshold
Low temperature alarm
The machine works normally
HAd
Temperature threshold
Defrosting probe high
temperature alarm
The machine works normally
LAd
Temperature threshold
Defrosting probe low
temperature alarm
The machine works normally
HAF
Temperature threshold
High fan temperature
alarm
The machine works normally
LAF
Temperature threshold
Low fan temperature alarm
The machine works normally
PA
Digital input
Blockage due to pressure
switch intervention
All outputs OFF
dA
Digital input
Open door
Compressor, fans OFF (depending on odc
parameter) and cold room light on.
Signalling, if set, following parameter d#d.
Resumes adjustment following parameter
(rrd) after any alarm
EA
Digital input
External alarm
The machine operates normally, only the
alarm relay is activated
CA
Digital input
External lockout alarm
(Compressor circuit breaker
alarm
/ fan circuit breaker alarm)
All outputs OFF
EE
-
Faulty EEPROM
All outputs OFF
6.1.2 EE Alarm
The board is equipped with a system to check the integrity of the internal memory. In case of problems, the
EE alarm appears.
In this situation, the alarm output is activated.
6.2 Serial line and network
The board has two built-in RS485 connections that allow the controller to interface for:
