RiverRidge 02-022 - Assembly Step 1; Assembly Step 2

STEP 1
STEP 2
1. Screw 4 cam bolts (B) into cam bolt holes on left side panel (2) and tighten.
2. Screw 4 cam bolts (B) into cam bolt holes on right side panel (3) and tighten.
1. Insert 1 screw (J) through hole on adjustable anchor bracket (F), then tighten to top board (1).
2. Screw 4 cam bolts (B) into cam bolt holes on top board (1) and tighten.
3. Insert 3 wood dowels (A) into bottom board (4).
4. Attach bottom trim (7) to bottom board (4) by inserting dowels into dowel holes on bottom
trim (7).
B
B
B
B
B
B
B
B
2
3
1
7
4
B
B
B
B
A
A
A
J
F
