RIX Industries MAN-2PS2B-N2 Page 1
Chapter 1 - Compressor Overview
1.1 Introduction
This manual is intended to provide all necessary information and documentation pertinent to the
installation, operation, and maintenance of the RIX compressor family 2PS2B-N2—models 2PS-L-
N2, 2PS-L50-N2, 2PS-H-N2, 2PS-H50-N2 & 2PS-HH-N2. Ensure all operators of this compressor
package read and understand the entire manual prior to installation, operation, and/or servicing.
All servicing shall be performed only by trained and qualified personnel.
1.2 Description
This is a 2 stage, 2 cylinder, air-cooled, oil-less compressor. This package is approximately 16
inches wide by 20.5 inches long by 29 inches tall and weighs approximately 172 lbs. See
Compressor Specifications for design operating pressures, flow rate, and gas type. Note the flow
rate will vary with the suction pressure, temperature, and compressor condition. This unit was
packaged by RIX as a ready to operate package with control and safety devices.
Pneumatic energy hazard. Unit is designed to compress and store
high pressure gas. When pneumatic energy is released in an
uncontrolled manner, individuals may be crushed or struck by
moving machinery, equipment, or other items. If maintenance is
attempted on a pressured line without isolating the line and relieving
pressure, the sudden release of pressure can propel fittings or
rupture lines or vessels. Ensure unit is depressurized and locked out
prior to performing any maintenance.
1.3 Cooling
Due to the heat generated during compression it is necessary to cool both the compression
cylinders and the compressed gas. Cooling fans are installed to blow air over the compression
assemblies and then route the air over the cooling coils. Ambient cooling air is required to be within
the range given in Compressor Specifications. Cooler air is desirable as it will increase
compressor component life.
1.4 Gas Compression
RIX compressors are designed to safely compress gas without cylinder oil lubrication. Teflon based
piston rings are used in all stages. Since oil is not used in the compression cylinders, the
compressor will not contaminate the compressed gas; however, it is the responsibility of the user to
ensure that clean gas is supplied to the compressor suction at all times. A small amount of inert
piston ring dust will pass into the gas stream; this can be filtered out if desired.
