RKC INSTRUMENT PF Series User Manual

1. OUTLINE
IMR02L04-E3
1-9
Digital output 3 (DO3)
Code Type Code Type Code Type
N None L Event 3 process low
with hold action
1 Event 3 manipulated output value
(MV1) high [heat-side]
A Event 3 deviation high P Heater break alarm 1 (HBA1) 2 Event 3 manipulated output value
(MV1) low [heat-side]
B Event 3 deviation low Q Heater break alarm 2 (HBA2) 3 Event 3 manipulated output value
(MV2) high [cool-side]
C Event 3 deviation high/low R Control loop break alarm (LBA) 4 Event 3 manipulated output value
(MV2) low [cool-side]
D Event 3 band S FAIL (de-energized fixed) 5 Time signal 1
E Event 3 deviation high
with hold action
T Feedback resistance (FBR) input
error
6 Time signal 2
F Event 3 deviation low
with hold action
U Event 3 band
(High/Low individual setting)
7 Time signal 3
G Event 3 deviation high/low
with hold action
V Event 3 set value (SV) high 8 Time signal 4
H Event 3 process high W Event 3 set value (SV) low 9 Pattern end signal
J Event 3 process low X Event 3 deviation high/low
(High/Low individual setting)
K Event 3 process high
with hold action
Y Event 3 deviation high/low
with hold action
(High/Low individual setting)
Digital output 4 (DO4)
Code Type Code Type Code Type
N None L Event 4 process low
with hold action
1 Event 4 manipulated output value
(MV1) high [heat-side]
A Event 4 deviation high P Heater break alarm 1 (HBA1) 2 Event 4 manipulated output value
(MV1) low [heat-side]
B Event 4 deviation low Q Heater break alarm 2 (HBA2) 3 Event 4 manipulated output value
(MV2) high [cool-side]
C Event 4 deviation high/low R Control loop break alarm (LBA) 4 Event 4 manipulated output value
(MV2) low [cool-side]
D Event 4 band S FAIL (de-energized fixed) 5 Time signal 1
E Event 4 deviation high
with hold action
T Feedback resistance (FBR) input
error
6 Time signal 2
F Event 4 deviation low
with hold action
U Event 4 band
(High/Low individual setting)
7 Time signal 3
G Event 4 deviation high/low
with hold action
V Event 4 set value (SV) high 8 Time signal 4
H Event 4 process high W Event 4 set value (SV) low 9 Pattern end signal
J Event 4 process low X Event 4 deviation high/low
(High/Low individual setting)
K Event 4 process high
with hold action
Y Event 4 deviation high/low
with hold action
(High/Low individual setting)
