 Output lamp [PF900: Green/PF901: White]
OUT1: Lights when output 1 is turned on.*
OUT2: Lights when output 2 is turned on.*
OUT3: Lights when output 3 is turned on.*
*
For voltage output or current output, the output lamp flashes when the output value goes below 0 %
and lights when the value goes above 0 %.
 State display lamp [Green or Orange]
The control mode in progress and the operation function lamps will be lit.
Character Lamp color Details
RESET
Green or
Orange
Reset mode (RESET) light will be orange.
When other modes are selected the light will be green.
RUN
Green or
Orange
Program control mode (RUN) light will be orange.
When other modes are selected the light will be green.
FIX
Green or
Orange
Fixed set point control mode (FIX) light will be orange.
When other modes are selected the light will be green.
MAN
Green or
Orange
Manual control mode (MAN) will be orange.
When other modes are selected the light will be green.
HOLD
Green
Light is green when HOLD key is operative.
STEP R.SET Green
Light is green when STEP R.SET key is operative.
STEP R.SET Green
Light is green when STEP R.SET key is operative.
PTN END Green
Light is green when PTN END key is operative.
PTN END Green
Light is green when PTN END key is operative.
Flashing of State display lamp
When Direct key type is “Press twice,” State display lamp flashes when the Direct key is
pressed once (except the PTN END key).
 Gradient state lamp [PF900: Green/PF901: White]
Lights the lamp of the gradient in process.
In the Program control mode (RUN):
Lights the lamp of the gradient of the segment in process.
Fixed set point control mode (FIX):
Lights soak lamp
In the Manual control mode (MAN) or the Reset mode (RESET):
Gradient state lamp does not light.
Rise Soak Drop
