Rlaarlo CT-8A - Coach Mode; Direction Mixing

5.5 Coach mode
Enter the Coach Mode interface through “Radio”--> “Training”.
The transmiter is equipped with a Type-C data cable, and 2 same transmitters can be directly connected with this
cable to activate the coaching function. The transmitter can be set as “Slave” role or “Master” role, the transmitter in
“Master” role directly controls the transmitter in “Slave” role.
The “Master” one can only control the signal values of channel 1 and channel 2 of the “Slave” one.
2.4G
Radio
Pairing
Fail Safe
Control
Postback
Training
Training
Null
PPM Port
Master
Type
Slave
4 / 5
5.6 Direction Mixing
Enter the Direction Mixing interface through “MIX Setup”--> “Direction”.
Directional mixing control is for Channel 1 and Channel 2. There are 4 mixing control modes in the transmitter, and
the mixing control mode can be set according to plays’ reqiurement.
MIX Setup
Direction
Program
Linearity
ESC Setup
Servos
3 / 5
Direction
Null
Apron Wheel
Boat A
Type
Boat B
Boat C
- 7 -
