RNA SCU1000 User Manual

Rhein-Nadel Automation GmbH 7
VT-BA-SCU1000-2000-EN_2019 / 27.06.2019 SJ
3.3. Technical data
Technical data
Power supply (can be changed internally):
230V AC, 50/60Hz, +10 -10%
or
115V AC, 50/60Hz, +10 -10%
Output voltage:
U
eff
40...208 V variable, (230V supply)
U
eff
20...105 V variable, (115V supply)
Load current:
max. 6 A(I
eff
)
Device fusing (power input):
2x miniature fuse 5 x 20mm
M6.3A/250V AC
Operating modes:
(depending on 50/60 Hz supply frequency)
Mode 1:
asymmetric half-wave mode
(vibrating frequency = mains frequency)
3000/3600 1/min
Mode 2:
symmetric full-wave mode
(vibrating frequency = double mains frequency)
6000/7200 1/min
Mode change:
Coding jumper in load connector
Enabling of functions:
internal/external
adjustable via parameters
Enabling input, external contact:
floating contact
Voltage source load capability: 24V DC, <10 mA
Enabling input, external 24V signal:
Level 16...30 VDC (polarized)
Signal current at 24V DC: < 10 mA
Status outputs
2x 24V DC, max. 30mA
Power loss:
max. 18W
Soft start / stop
Default setting 0.1s
adjustable via parameters
Degree of protection:
IP 54
Radio interference suppression:
acc. to EMC directive
Dimensions:
130 x 203 x 135 (width x height x depth)
Ambient temperature:
0°C to 40°C
Storage temperature
-20°C to 70°C
Air humidity:
15% to 85% not condensing
Atmospheric pressure:
86 kPa to 106 kPa
Cooling:
free convection
Weight:
approx. 1.6 kg
Housing material:
Aluminium/plastics
Installation position:
Vertical
Mounting
vibration-free
Attention!
Any intervention on the controller shall void the manufacturer's warranty.
This does not apply to
- proper installation of the I/O retrofit kit
- proper change of supply voltage
- proper connection of external enabling signal
in accordance with these operating instructions.
