RNA SCU1000 User Manual

Rhein-Nadel Automation GmbH 8
VT-BA-SCU1000-2000-EN_2019 / 27.06.2019 SJ
3.4. Products, spare parts and accessories
Designation
Design
RNA mat. code No.
SCU1000
not pluggable
without enabling and status signals
31002800
SCU2000
completely pluggable
with enabling and status signals
without power input cable
31002810
SCU2000
completely pluggable
with enabling and status signals
with power input cable
31002812
Designation
Connector
Design
RNA mat. code No.
Power input cable
SCU2000
X0
Length: 1.9 m
Shockproof plug and power plug (SCU2000)
31002811
Vibrating drive
connector
X1
Plug with 4 pins + PE
Metal housing
31002323
Connecting cable
for enabling and
status signals
X21
X22
Length: 5.0m
Straight M8 4-pin connector
Zero-halogen PUR
Free cable end
39004437
Length: 5.0m
Angular M8 4-pin connector
Zero-halogen PUR
Free cable end
39004439
Connector for ena-
bling and status
signals
X21
X22
Straight M8 4-pin connector
screw connection
Outside cable dia.: 3,5 mm ... 5 mm
35051703
M8x1 cable gland
with lock nut
Connection of ex-
ternal enabling sig-
nal for SCU1000
For outside cable diameter: 3,5 mm ... 5 mm
31002803
Designation
Description
RNA mat. code No.
Measuring adapter
ESZ-02
(400V/10A)
Accessory for measurement of output voltage and output current.
The adapter is supplied with connectors.
31002525
I/O retrofit kit
Accessory for SCU1000 for retrofitting the enabling and status
signals
31002801
