28
Password Protection - allows to enter password in order to prevent unauthorized person from changing set-
ting of the xture.
7.4 Tab "Manual Control"
Reset Functions - The menu allows to reset the xture either per function modules or all modules together.
Total System Reset - The item resets all function modules.
Pan,Tilt Reset - The item resets a pan and tilt movement (except Follow Spot Mode).
Colour System Reset - The item resets a colour wheels and CMY/CTO ags.
Gobo System Reset - The item resets rotating gobo wheels.
Dimmer, Strobe Reset - The item resets strobe and shutter lamellas .
Optics,Prism,Frost Reset - The item resets a zoom, focus, prism and a frost module.
Iris,Fr. Sh., Eff. wh Reset - The item resets an iris, effect wheel and framing shutters.
Manual Effect control - Use the menu to control all xture channels by means of the control panel.
7.5 Tab "Stand-alone"
Test Sequences -Use the menu to run a test/demo sequences without an external controller, which will show
you some possibilities of using Robin BMFL Blade.
Dynamic Mode - This mode uses all Robin BMFL Blade functions including pan/tilt movement and there-
fore
is good for a complete introduction of the xture.
Static Mode - This mode is suitable for projections on the wall, ceiling or ground without any pan/tilt move-
ment. Adjust the pan, tilt, zoom, focus and hot-spot to desired positions an start test sequences by touching
the green icon.
Music Trigger - Use the item to activate the sound control of the running program via the built-in micro-
phone.
Preset Playback - This menu allows you to select the program which will be played in a loop after switching
the xture on (the option is commonly used in a stand-alone operation without an external controller).
None - The option disables “Presetting playback” function.
Test - The option starts the test sequences.
Prog. 1 - The option starts user program No. 1.
Prog. 2 - The option starts user program No. 2.
Prog. 3 - The option starts user program No. 3.
Play program - Use the menu to run desired program in a loop.
Play Program 1 - The option starts user program No.1.
Play Program 2 - The option starts user program No. 2.
Play Program 3 - The option starts user program No. 3.
Edit Program - Use the menu to create or to edit desired program. The Robin BMFL Blade offers 3 free pro-
grams, each up to 100 steps.
Edit Program 1 - The option allows to edit user program No.1.
Edit Program 2 - The option allows to edit user program No.2.
Edit Program 3 - The option allows to edit user program No.3
To edit program:
1. Touch the item which you want to edit (“Edit Program 1” - “Edit Program 3”).
2. Touch the item "Edit Program Steps".
3. Touch the item "Step 1".
4 From the list of effects touch desired effect and set its value. Browse throw the list by touching the [up arrow]
and [down arrow] and set all desired effects.
