Robe Robin BMFL Blade - Calibration Protocol: More Effects to DMX Channels; Loading Default Calibrations; Calibrating Pan;Tilt EMS; Software Update Procedure

31
Effect wheel channel 58 channel 51
Static gobo channel 59 channel 52
Rot. Gobo Wheel channel 60 channel 53
R. Gobo Index 1 channel 61 channel 54
R. Gobo Index 2 channel 62 channel 55
R. Gobo Index 3 channel 63 channel 56
R. Gobo Index 4 channel 64 channel 57
R. Gobo Index 5 channel 65 channel 58
R. Gobo Index 6 channel 66 channel 59
Prism 1 channel 67 channel 60
Prism 1 Rot channel 68 channel 61
Prism 2 channel 69 channel 62
Zoom channel 70 channel 63
Frost 1/1 channel 71 channel 64
Frost 1/2 channel 72 channel 65
Frost 2/1 channel 73 channel 66
Frost 2/2 channel 74 channel 67
Focus 1 channel 75 channel 68
Focus 2 channel 76 channel 69
Iris channel 77 channel 70
Strobe 1/1 channel 78 channel 71
Strobe 1/2 channel 79 channel 72
Strobe 2/1 channel 80 channel 73
Strobe 2/2 channel 81 channel 74
Dimmer 1/1 channel 82 channel 75
Dimmer 1/2 channel 83 channel 76
Dimmer 2/1 channel 84 channel 77
Dimmer 2/1 channel 85 channel 78
Diffusor channel 86 channel 79
Fr. Shutters Rot. channel 87 channel 80
Fr. Reset 1 M1 channel 88 channel 81
Fr. Reset 1 M2 channel 89 channel 82
Fr. Reset 2 M1 channel 90 channel 83
Fr. Reset 2 M2 channel 91 channel 84
Fr. Reset 3 M1 channel 92 channel 85
Fr. Reset 3 M2 channel 93 channel 86
Fr. Reset 4 M1 channel 94 channel 87
Fr. Reset 4 M2 channel 95 channel 88
Fr. Shutter 1 Mov. channel 96 channel 89
Fr. Shutter 1 Swiv. channel 97 channel 90
Fr. Shutter 2 Mov. channel 98 channel 91
Fr. Shutter 2 Swiv. channel 99 channel 92
Fr. Shutter 3 Mov. channel 100 channel 93
Fr. Shutter 3 Swiv. channel 101 channel 94
Fr. Shutter 4 Mov. channel 102 channel 95
Fr. Shutter 4 Swiv. channel 103 channel 96
After having calibrated all effects, touch the [conrm] to save adjusted values and reset the xture.
Load Default Calibrations - The item loads default (factory) calibration values.
Calibrate Pan/Tilt EMS - This menu item allows calibration of the pan/tilt electronic motion stabilizer.
Important: during this calibration any external force must not inuence the xture and the surface at which
the xture stands (or truss if the xture hangs) has to be without movement, shake, strokes etc.
Updating software - The menu item allows you to update software in the xture via either serial or USB port
of PC.
The following are required in order to update software:
- PC running Windows 95/98/2000/XP/7/8 or Linux
- DMX Software Uploader
- Flash cable RS232/DMX No.13050624 (if you want to use a serial port of PC)
- Robe Universal Interface (if you want to use an USB port of PC)
Note: Software update should execute a qualied person. If you lack qualication, do not attempt the
update yourself and ask for help your ROBE distributor.
