Robe Robin LedBeam 150 - Reset; Special Functions (Special)

16
C Mix C a colour mix control
Zoom a zoom function
Zoom F a zoom function ne
Stro a strobe/shutter function
Dimm a dimmer function coarse
Dim F a dimmer function ne
F.Tim a fade time (0-25.5 sec)
S.Tim a step time (0-25.5 sec)
COPY copying the current prog. step to
the next prog. step
4. Press [ENTER] button to conrm adjusted value .
5. Press [ESCAPE] button, select next prog. step, press [ENTER] button and repeat steps 3 - 5).
5.7 Reset
This option enables the ROBIN LEDBeam 150 to index all e󰀨ects and return to their standard positions.
5.8 Special functions (Special)
RDM Low - This menu item shows the rst part of the RDM identication code.
RDM High - This menu item shows the second part of the RDM identication code.
Wireless - Wireless DMX information. The menu allows to read some information about
Wireless DMX operation
Stat - Wireless status. Use the menu to read wireless DMX status.
Unlink - use this item to unlink xture from wireless DMX.
Adjust - Adjustment. The menu allows the ne adjustment of e󰀨ects.
DMX Val- DMX values. Use the menu to set DMX values of xture´s channels.
Calib - calibration of white colour.
Cal Mech - Use this menu to calibrate pan/tilt/zoom position.
Cal Col - Use this menu to set white colour 5600K.
Calibration of the pan/tilt/zoom via the control board
1. Disconnect DMX controller from the xture and enter the "Cal Mech" menu.
2. Use the [PREV] and [NEXT] to nd "Pan C" and press [ENTER].
3. Set desired value and save it by pressing [ENTER].
4. Repeat steps 2 and 3 for "Tilt C" and "Zoom C".
5. After calibrating both e󰀨ects, nd item "Store" and press [ENTER]. to save all adjusted values and reset the
xture.
Calibration of the white 5600K via the control board
1. Disconnect DMX controller from the xture , set the shutter, dimmer and RGBW channels at 255 DMX, zoom
at 128 DMX and the CTC channel at DMX=64 (white 5600K). Aim the light beam on the lux meter (e.g. Minolta
CL-500 A Chroma meter) which is placed cca 5m from the xture.
2. Set the menu items Colour Mix Mode to RGBW and "White Point 8000K to On (Pers-> C Mix M -> RGBW,
Pers-> White P -> On).
3. Enter the menu "Cal Col".
4. By means of the "Red C, Gre C, Blu C and Whi C" items adjust the 5600K colour temperature
as exactly as possible (∆u´v´= 0).
5. After adjusting 5600K colour temperature, select item Store and press the [ENTER] button to save all
adjusted values .
Note: you can also use DMX controler for both calibrations stated above, calibration protocol is the following:
Eect Mode 1 Mode 2
Pan-ne adjustment channel 23 channel 17
Tilt - ne adjustment channel 24 channel 18
