Robe Robin LedBeam 150 - DMX Protocol

DMX protocol
1
2
1 1
Pan (8 bit)
0 - 255 Pan movement by 540° (128=default) proportional
2 2
Pan Fine (16 bit)
0 - 255 Fine control of pan movement (0=default) proportional
3 3
Tilt (8 bit)
0 - 255 Tilt movement by 228° (128=default) proportional
4 4
Tilt fine (16 bit)
0 - 255 Fine control of tilt movement (0=default) proportional
5 5
Pan/Tilt speed , Pan/Tilt time
0 Max. speed -tracking mode (0=default) step
Pan/Tilt speed
1 - 255 Speed from max. to min. (vector mode) proportional
Pan/Tilt time
1 - 255 Time from 0.1 s to 25.5 sec. proportional
6 6
Power/Special functions
0 -19 Reserved (0=default)
To activate following functions, stop in DMX value for at least 3 s
and shutter must be closed at least 3 sec. („Shutter,Strobe”
channel 20/15 must be at range: 0-31 DMX). Corresponding menu
items are temporarily overriden.
20-24
Display ON
step
25-29
Display OFF
step
30-34
RGBW colour mixing mode
step
35-39
CMY colour mixing mode
step
40-44 Pan/Tilt speed mode step
45 - 49 Pan/Tilt time mode step
50 -54 Blackout while pan/tilt moving step
55 -59 Disabled blackout while pan/tilt moving step
60 - 64 Dimmer curve - square law step
65 - 69 Dimmer curve - linear step
70 - 74
Fans mode: Auto
step
75 - 79
Fans mode: High
step
80-84
White point 8000K ON
step
85-89
White point 8000K OFF
step
90-94
Fans mode: Quiet
step
95 -129
Reserved
To activate following functions, stop in DMX value for at least 3
seconds.
130 - 139 Reserved
140 - 149 Pan/Tilt reset step
150 - 159 Zoom reset step
160 - 169 Reserved step
Tungsten effect simulution for whites 2700K and 3200K
170-171 Tungsten effect simulation (750W) On step
172-173 Tungsten effect simulation (1000W) On step
174-175 Tungsten effect simulation (1200W) On step
176-177 Tungsten effect simulation (2000W) On step
Robin LedBeam 150 - DMX protocol
Version: 1.2 Mode 1-Standard 16-bit, Mode 2 -Reduced 8-bit
Mode/channel
DMX
Value
Function
Type of
control
Page 1
