DMX protocol
Channel
DMX
Value
Function
Type of
control
Type of control 6
0 Open step
1-255 Mask effect from min. level to max. level proportional
Type of control 7
0-127 Movement from edge to centre proportional
128 Centre step
129--255 Movement from centre to edge proportional
Type of control 8
0-255 Continuous effect changing proportional
23
Shutter/ strobe
0 - 31 Shutter closed step
32 - 63 Shutter open step
64 - 95 Strobe-effect from slow to fast proportional
96 - 127 Shutter open step
128 - 143 Opening pulse in sequences from slow to fast proportional
144 - 159 Closing pulse in sequences from fast to slow proportional
160 - 191 Shutter open step
192 - 223 Random strobe-effect from slow to fast proportional
224 - 255 Shutter open step
24
Dimmer
0 - 255 Dimmer intensity from 0% to 100% proportional
