DMX In - DMX readout. The menu is used to read DMX values of each channel received by the xture.
Hea Temp - Head temperature. The menu shows temperature in the xture´s head.
Current - A current temperature of the head.
Highest - A maximum temperature of the the head since the xture has
been fabricated.
High Res - A maximum temperature of the the head since the counter
was last reset.
In order to reset this counter, press and hold both [NEXT] and [PREV] buttons and then order to reset this counter, press and hold both [NEXT] and [PREV] buttons and thepress and hold both [NEXT] and [PREV] buttons and the
[Enter] button at the same time.
Sw Ver - Software versions. Select this item to read the software version of the xture modules.
IC-1 - A pan/Tilt processor.
IC-2 - A display processor.
IC-3 - LED control processor.
IC-4 - LED control processor.
6.3 Personality (Pers)
DMX Pres - DMX preset. Use the menu to select desired channel mode.
Mode 1 - 27 control channels
Mode 2 - 21 control channels
Pan Rev - Pan reverse. The item allows to invert pan movement.
Tilt Rev - Tilt reverse. The item allows to invert tilt movement.
P/T Mode - Pan and Tilt movement mode. Use this menu to set mode of the pan/tilt movement.
Speed - Both Pan and tilt will move with the same speed as adjusted at the channel
"Pan/Tilt speed, Pan/Tilt time".
Time – The pan and tilt will move with different speeds and they will come at
the same time to the end point of their tracks (pan and tilt use their optimal speeds).
Time of the pan/tilt movement (25.5 sec. max.) is set by the channel "Pan/Tilt speed, Pan/Tilt
time".
P/T Feed - Pan and Tilt Feedback. The menu item allows to return the mowing head to the required pan/tilt
position after changing the position by an external force if this option is set on.
Note. The Pan/Tilt Feedback should be permanent On, the option Off is not suitable for standard operation and
the head of the xture can be damaged!
Display - Display adjusting. This menu allows you to adjust the display behaviour.
Turn - This function rotates menu 180 degrees from current orientation..
On/Off T - This function allows you to keep the display permanent on (On/Off T= Off)
or turn it off two minutes after last pressing any button on the control panel (On/Off T= On).
Contrast- Use this function to adjust contrast of the display (0-100%).
Backlight- Use this function to adjust backlight of the display (0-100%).
BLC DMC - Blackout during movement correction. Set this option on if you wish to close light
output during the time when the head goes to its correct position, which has been changed by an
external force.
BLC P/T - Blackout at P/T movement. The menu item allows to close light output while pan/tilt coordinates
are changing.
C Mix M - Colour mixing mode. This item allows switching into RGBW or CMY mode. In the CMY mode, the
white(8bit)/white (16) bit channels are not active.
White P - If the function is on, the CTC channel allows to set desired white in range of 8000K-2700K
(0 DMX=8000K, 255 DMX=2700K). Necessary condition is , that RGBW channels have to be full or set at the
same DMX values, e.g. 255.
If this function is off, the range of whites is not uniform and may be different for each xture.
Mic Sens - Microfon sensitivity. Enter the menu if you want to adjust the microphone sensitivity ( 0-max.,
19-min.).
