18
Tilt C a tilt continual movement
P/T Sp a pan/tilt speed
Powr power/special functions
Virt C a virtual colour wheel
Red a red colour coarse
Red F a red colour ne
Green a green colour coarse
Green F a green colour ne
Blue a blue colour coarse
Blue F a blue colour ne
White a white colour
White F a white colour ne
CTC a colour temperature correction
C Mix C a colour mix control
Prism a rotating prism
Flow E a ower effect
Flow ER a ower effect rotation
Zoom a zoom function
Zoom F a zoom function ne
Stro a strobe/shutter function
Dimm a dimmer function coarse
Dim F a dimmer function ne
F.Tim a fade time (0-25.5 sec)
S.Tim a step time (0-25.5 sec)
COPY copying the current prog. step to
the next prog. step
4. Press [ENTER] button to conrm adjusted value .
5. Press [ESCAPE] button, select next prog. step, press [ENTER] button and repeat steps 3 - 5).
6.7 Reset
This option enables the Robin Spikie to index all effects and return to their standard positions.
6.8 Special functions (Special)
RDM Low - This menu item shows the rst part of the RDM identication code.
RDM High - This menu item shows the second part of the RDM identication code.
Wireless - Stat - Use the menu to read wireless DMX status.
Unlink - use this item to unlink xture from wireless DMX.
Adjust - Adjustment. The menu allows the ne adjustment of effects.
DMX Val- DMX values. Use the menu to set DMX values of xture´s channels.
Calib - calibration xture effects.
Cal Mech - Use this menu to calibrate mechanical effects:
Pan C - position of the pan
Tilt C - position of tilt
Pr1 C - position of prism
Pr2 C - prism rotation
Fl1 C - ower effect frost movement
Fl2 C - ower effect rotation ne
Zoom - Zoom position ne
Cal Col - Use this menu to calibrate white colour 5600K.
Calibration of the pan/tilt via the control board
1. Disconnect DMX controller from the xture and enter the "Cal P/T" menu.
2. Use the [PREV] and [NEXT] to nd "Pan" and press [ENTER].
3. Set desired value and save it by pressing [ENTER].
