25
2. Remove the plastic covers of the base (1) by unscrewing two
fastening screws (2) on each cover.
3. Unscrew four screws (3) on the top chassis (4). Lay down
the xture and unscrew four screws (5) on the bottom plate
(8) to push out inside module of the base.
4. Unscrew two screws (7) on the bottom plate to remove
rear panel of the xture (6).
5. Now you have access to the fuse holder (9) in
the inside module of the base.
6. Remove the old fuse from the fuse holder.
7. Install the new fuse into the fuse holder.
8. Assemble the base of the xture.
10.1 Replacing the fuse
Before replacing the fuse, unplug mains lead!
1.Replace the fuse by a fuse of the same type and rating only.
