Calibration protocol:
E󰀨ect Mode 1 Mode 2 Mode 3
Pan channel 36 channel 25 channel 40
Tilt channel 37 channel 26 channel 41
Zoom channel 38 channel 27 channel 42
Focus channel 39 channel 28 channel 43
Frost 1/1 channel 40 channel 29 channel 44
Frost 1/2 channel 41 channel 30 channel 45
Frost 2/1 channel 42 channel 31 channel 46
Frost 2/2 channel 43 channel 32 channel 47
Fr. Shutters rot. channel 44 channel 33 channel 48
Barndoors rotation channel 45 channel 34 channel 49
Barndoor 1 move channel 46 channel 35 channel 50
Barndoor 2 move channel 47 channel 36 channel 51
Barndoor 3 move channel 48 channel 37 channel 52
Barndoor 4 move channel 49 channel 38 channel 53
Scrim positioning channel 50 channel 39 channel 54
Scrim indexing channel 51 channel 40 channel 55
Calibrate Colours - The menu serves for calibration of white colours in a factory.
Green Corrections - The menu allows you to correct calibrated whites 2700K, 3200K, 4200K, 5600K and
8000K. Both shutter and dimmer have to be open during the correction.
Calibrate Pan/Tilt EMS - This menu item allows calibration of the pan/tilt electronic motion stabilizer.
Important: during this calibration any external force must not inuence the xture and the surface at which
the xture stands (or truss if the xture hangs) has to be without movement, shake, strokes etc.
Load Default Calibrations - The item loads default (factory) calibration values.
LEDS HW version - The item shows a hardware version of the LED engine.
Front Lens - In case that front lens is changed, the corresponding item (PC lens or Fresnel lens) has to be
selected in order to get correct calibrated whites.
Fresnel lens installed - select the item Fresnel Lens.
PC lens installed- select the item PC Lens.
Update software - The menu item allows you to update software in the xture.
The following items are required in order to update software:
- PC running Windows or Linux or macOS
- DSU le
- Flash cable RS232/DMX, P/N13050624 (if you want to use a serial port of PC)
- Robe Universal Interface or Robe Universal interface WTX (if you want to use an USB port of PC)
After software updating the xture will be set to default values.
To update software in the xture:
1. DSU le is available from Robe web site at WWW.robe.cz.
File with extension zip is intended for Windows (used and tested from XP to W10 on 32/64bit systems).
File with extension tbz is intended for Linux (used and tested on Debian and Ubuntu 32/64bit).
File with extension dmg is intended for macOS (used and tested on OSX up to Sierra) XQuartz required,
install it from https://www.xquartz.org/
Save the download le to a folder on your computer.
In case that you use windows, extract les in the zip le (e.g. DSU_RobinT1Wash_18100828.zip)
2. Disconnect the xture from DMX controller.
3. If you use the ash cable RS232/DMX, connect a serial port of your computer with DMX input of the xture
by means of the cable.
If you use the Robe Universal Interface, connect a USB port of your computer with the Robe Universal Interface
by means of the USB cable and DMX input of the xture with the DMX output of the Robe Universal Interface
via a DMX cable.
