THERMOSTAT OPERATION
1
2
3
4
5
LCD Screen
See page 4 for details about this
display read out.
Fan Switch
Select ON or AUTO. ON will
runthe fan continuously.
AUTOwill cycle the fan on only
when the heating or cooling
system is running.
System Switch
Selects the HEAT or COOL for
your HVAC system. Selecting
HEAT turns on the heat mode.
Selecting COOL turns on the
cool mode. Selecting OFF turns
both heating and cooling off.
Selecting EMH (for heat pumps
with auxiliary heat) will lockout
the compressor and control
emergency/auxiliary heat.
Temperature Set-Point
Buttons
Press the or to select
the desired temperature.
Use these buttons to set up
programming options.
User Buttons
3
