Robertshaw RS9110 Installation Manual

SPECIFICATIONS
Specications
Temperature Display Range ............... 41°F to 95°F (5°C to 35°C)
Temperature Control Range ............... 44°F to 90°F (7°C to 32°C)
Load Rating ........................................ 1 amp per terminal, 1.5 amp maximum all terminals combined
Display Accuracy ................................ ± 1°F
Differential........................................... Heating is adjustable from 0.2°F to 2.0°F
Cooling is adjustable from 0.2°F to 2.0°F
Power Source ..................................... 18 to 30 VAC, NEC Class II, 50/60 Hz for hardwire (common wire)
Battery power from 2 AAA Alkaline batteries
Operating Ambient Temperature ........ 32°F to +105°F (0°C to +41°C)
Operating Humidity ............................ 90% non-condensing maximum
Dimensions ......................................... 4.72”W x 3.86”H x 0.98”D
23

Robertshaw RS9110 Specifications

General

Brand	Robertshaw
Model	RS9110
Category	Thermostat
Language	English
