3.
DISASSEMBLY AND REASSEMBLY
3-
1
PREPARATIONS
AND
SUGGESTIONS
(1)
When disassembling an engine
,
memorize well the locations
of
individual
parts
so
that they
can be reassembled correctly.
If
you are uncertain of identifying some
parts,
it is suggested
that tags to be attached to them.
(2)
Have boxes ready to keep disassembled parts by group.
(3)
To
prevent missing and misplacing small parts such
as
bolts and nuts, etc., temporarily
assemble
as
much as possible in each group
or
set.
(4)
Carefully handle disassembled parts, and clean them with washing oil.
(5)
Use correct tools in correct way.
(6)
Standard tools required
for
disassembling and reassembling
:
a) Work table
b) Washing pan
c) Disassembling tools
d)
Washing oil (kerosene
or
light oil)
e) Emery paper, waste '.cloth
(7)
Before starting disassembly
of
the engine, drain fuel.
3-2
SPECIAL
TOOL
Tool
No.
Use
Tool
560
-
90020
-
00
For
pulling
off
the flywheel
and
clutch
Clutch puller
"--(NOTE]-
Use tKree
(3)
M5
X
40mm bolts
with the puller to remove clutch,
and
two
(2)
M6
X
4Omm bolts to
remove
flywheel.
Fig.
1
-3-
To Next Page
