Description
Part
No.
QtY
Remarks
1
Flywheel Puller
EY14, EY18-3, EY23, EY25-2, EY27-2
1
2079500307 Valve
Spring
Compressor
3
001
6608500
Bolt
1
209 95004 07
EY14, EY18-3, EY23, EY25-2, EY27-2
I
I
205 95001
07
I
1
I
EY
14
I
Valve Guide Puller
(Plate,
Shaft,
Nut)
I
I
206 95001 07 EY 18-3, EY 23
1
207 95001 07
EY25-2, EY27-2
1
Valve Seat Cutter
EY14, EY18-3, EY23, EY25-2, EY27-2
1
2079500207
6-3
DISASSEMBLY
and
REASSEMBLY
PROCEDURES
6-3-1 FUEL
TANK
and FUEL TANK BRACKET
1)
Disconnect fuel pipe between strainer and carburetor
at
carburetor side.
2)
Remove fuel tank from
bracket.
(8
mm
nut,
4
pieces)
(EY14:
3
pieces)
3)
Remove tank
bracket
from cylinder
head
(EY14:
8
mm flange nut/EY18-3, EY23, EY25-2,
EY27-2: 10 mm flange nut, 4 pieces)
6-3-2 BLOWER HOUSING and HEAD COVER
1)
Remove blower housing from crankcase and head cover (cylinder baffle).
(EY14: 6
x
8
mm Flange bolt, 6 pieces/EY18-3,
EY23,
EY25-2, EY27-2: 6
x
12 mm Flange
bolt, 6 pieces)
2)
Remove head cover (cylinder baffle) from cylinder head.
-
6-3-3 AIR CLEANER
1)
Remove air cleaner cover and element.
2)
Loosen two bolts and remove air cleaner
case
from carburetor. (EY14:
6
x
8
mm Flange bolt
2
pieces/EY18-3, EY23, EY25-2, EY27-2:
6
x
10 mm bolts,
'2
pieces) (EY25-2, EY27-2:
at
the
same
time,
disconnect choke knob
that
is
connected
to
carburetor choke lever.)
3)
Disconnect breather
pipe.
4)
In
reassembly, wash element in kerosene shaking well until
dirt
is
sufficiently removed. Dry
element thoroughly and apply mixture'of 4
part
kerosene and
1
part Mobile oil. Squeeze out
excess oil before reinstalling it.
6-3-4 MUFFLER
Remove muffler from cylinder part of crankcase. (EY14, EY18-3, EY23, EY25-2, EY27-2:
8
mm
nut,
2
pieces)
6-3-5 GOVERNOR LEVER and CARBURETOR
1)
Remove governor lever from governor
shaft.
(6
mm
bolt,
1
pieces)
2)
Remove governor rod and
rod
spring from carburetor.
3) Remove carburetor from cylinder part
of
crankcase.
(6mm
nut,
2
pieces)
In
reassembly, refer
to
8.
GOVERNOR ADJUSTMENT section.
6-3-6 STARTING PULLEY and MAGNETO
1)
Remove starting pulley from flywheel.
(EY14:
6
x
12
mm bolt/EY25-2,
EY27-2:
8
x
12
mm
-
bolt, 3 pieces)
-
22
-
