– 12 –
(7) "Dr.Robin" GENERATOR TESTER
The "Dr.Robin" generator tester is exclusively
designed for fast, easy diagnosis and repair of Robin
generators. The "Dr.Robin" has the following features :
1) Functions of voltmeter, frequency meter, megger
tester, capacitance meter and circuit tester are
combined in one unit.
2) Fast and easy readout by digital indicator.
3) Built-in automatic battery checker indicates the
time to change batteries.
4) Tester and accessories are installed in a handy,
sturdy case for easy carrying.
SPECIFICATIONS
MODEL Dr.Robin
Part Number
388-47565-08
Measuring
Range
0 to 500 V AC
25 to 70 Hz
0.1 to 1,999 Ω
10 to 100 μF
3MΩ
Circuit Protector
Fuse
Power Source
2 x 6F44P (006P) Dry Cell Battery
Accessories
Test leads with needle probes ... 1 set
Test leads with jack plugs ... 1 set
Dimensions (L x W x H)
285 mm x 200 mm x 110 mm
Weight
1.6 kg
Voltage
Frequency
Resistance
Condenser Capacity
Insulation Resistance
The "Dr.Robin" generator tester can be ordered from Robin generator distributors by the following part number.
Dr.Robin_Part_Number_:_388-47565-08
If you do not have a "Dr.Robin" generator tester, use the instruments described in the following section for
checking generator parts.
