Robin R1700i Service Manual

– 3 –
2-2) CONTROL PANEL
DC TERMINALS
GROUND TERMINAL
AC RECEPTACLES
DC CIRCUIT BREAKER
ENGINE SWITCH
OVERLOAD LAMP
PILOT LAMP
OIL SENSOR LAMP
AUTO POWER SAVE SWITCH
AUTO POWER SAVE LAMP
R1700i
ENGINE SWITCH
RUN
STOP
CHOKE
(1) ENGINE SWITCH
The engine switch is designed for easy operation with the
interlocking mechanism between the fuel cock and the choke
furnished.
(CHOKE)
To start the engine, turn the knob to the position.
(Choke valve is closed.)
"" (RUN)
Keep the knob in this position after the engine starts.
(The engine can be started with the knob at this position
when the engine is warm.)
"" (STOP)
To stop the engine, return the knob to the position.
(The fuel cock is closed as well.)
