Robomow RC308u User Manual

60
61
Setting Description
P004* Max Near-Wire Follow Distance
Maximal allowed distance from the edge, when P003 is On.
P005* Min Near-Wire Follow Distance
Minimal allowed distance from the edge, when P003 is On.
P006* Near Wire Follow Test
Test the mower at the max distance set in P004.
P007 Rain Sensor On/Off
Automatically halt operation in rainy weather.
P008 Rain Sensor Sensitivity
Set higher value for higher sensitivity to rain.
P009 Edging On/Off
Enable/disable automatic edge-mowing.
P010 Child Lock On/Off
Lock the keypad to prevent accidental press.
See section 5 further.
P011 Anti-Theft On/Off
Enable and set a 4-digit PIN-code for protection.
See section 5 below.
P012 Anti-Theft PIN-code
Change and confirm new anti-theft PIN code.
See section 5 below.
P013 Base Station On/Off
Set an additional base for a separated zone.
P014 Add Separated Zone
Define a new separated zone and set its area size.
P015 Remove Zone
Delete a separated zone or a sub-zone.
P016 Sound On/Off
Disable operating sounds.
(*) This setting is not applicable to models for lawns under 800 m
2
/8600 ft
2
.

Robomow RC308u Specifications

General

Type	Robotic lawn mower
Noise level	69 dB
Cutting width	280 mm
Grass catcher	-
Product color	Green
Cutting system	Rotary blades
Number of wheels	3 wheel(s)
Maximum working climb	36 %
Recommended lawn area	800 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Cutting clearance adjustment	6
Battery type	Built-in
Power source	Battery
Charging time	1.5 h
Battery voltage	26 V
Battery capacity	3 Ah
Battery life (max)	70 min
Battery technology	Lithium
Power consumption per month (max)	18 kWh

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
