Robomow RC308u User Manual

60
61
Setting Description
P017 Mobile Communication System
Enable GSM module accessory (if installed).
P018 Statistics On/Off
Send operating statistics for diagnostics.
P019 Bluetooth Remote Control Pairing
Pair Remote Control accessory with your mower.
P020 Last Termination Event
Enable special debug mode (by a Service Station).
P021 Program On/Off
Enable/Disable automatic operation by zone.
See section 4 further.
P022 Add Sub-Zone
Start the process of adding a sub-zone.
Refer to the“Adding Sub Zones” section of the Installation
Manual.
P023 Update Distance to Sub-Zone
Update the distance to the Sub-Zone’s entry point.
This menu option is only shown if a Sub-Zone is defined.
P024 SmartMow On/Off
Increase mowing efficiency.
May be less efficient with particular lawn shapes.
P025 SmartMow Edge Overlap
Optimize SmartMow mode for your lawn.
P026 Turbo Mow On/Off
Enable faster and stronger cut. When the mowing cycle
is completed, this feature is set to off automatically.
P027 RoboHome On/Off
Allow proper rain detection when RoboHome is installed.
P028 External Base
Enable and set the distance of an external base installation.

Robomow RC308u Specifications

General

Type	Robotic lawn mower
Noise level	69 dB
Cutting width	280 mm
Grass catcher	-
Product color	Green
Cutting system	Rotary blades
Number of wheels	3 wheel(s)
Maximum working climb	36 %
Recommended lawn area	800 m²
Maximum cutting height	60 mm
Minimum cutting height	15 mm
Grass collecting volume	- L
Cutting clearance adjustment	6
Battery type	Built-in
Power source	Battery
Charging time	1.5 h
Battery voltage	26 V
Battery capacity	3 Ah
Battery life (max)	70 min
Battery technology	Lithium
Power consumption per month (max)	18 kWh

Weight and Dimensions

Depth	460 mm
Width	630 mm
Height	210 mm
Weight	11400 g
