Robomow RS615 Pro - Page 31

14 cm [5.5 in]
32 cm
[12.6 in]
Main Zone
Sub Zone
Two wires
under
same peg
70 cm [27.5 in]
Min 50 cm (19.7 in)
Min 50 cm (19.7 in)
70 cm [27.5 in]
28
29
• If a Narrow Pass is shorter than 2 m [7 ft], set up only one
square Perimeter Island in the passage
• Take care to wire Narrow Passes correctly to ensure that the
mower doesn’t cross into different zones spontaneously while
mowing
Narrow Passes should be firm, level, and smooth.
TIPS
A helpful video
is available
online
