Robopac R-CONNECT - Masterplat - Rotoplat - Technoplat Cs-Cw - Rotoplat Dw-Dwc

R- CONNECT
INSTALLATION
Date:
August 2019
Rev.03
ENGLISH
Pag. 46 / 61
MASTERPLAT – ROTOPLAT – TECHNOPLAT CS-CW – ROTOPLAT DW-DWC
The new roll has to MOUNTED at the place of the carriage emergency roll (see below (R)), the SENSOR can be mounted
on two different available holes (different for different carriages …)
