D16
Cleaning the Air Duct
Follow the following steps to clean the air
duct and avoid blockages.
*
Clean as required.
D16-1—Remove the clean water tank, dirty
water tank, and dustbin.
D16-2—Remove the water lter and wipe
o any water marks with a cloth.
D16-3—Carefully place the the dock upside
down on a hard oor covered with a
soft towel. Unscrew the eight screws
and remove the cover.
D16-4—Wipe the air duct and duct cover
with a dry cloth. Re-install the cover
and screw it back in place.
Basic Parameters
Model Q100TSC
Battery
14.4 V/5200 mAh lithium-ion
battery
Rated Input 20VDC 1.5A
Charging Time Approx. 4 hours
Robot
Model EWFD04HRR or EWFD05HRR
Rated Input
Voltage
220-240VAC
Rated Frequency 50-60Hz
Rated Input
(Dust Collection)
5A
Rated Input
(Non-Dust
Collection)
0.65A
Rated Output 20VDC 1.5A
Battery
14.4 V/5200 mAh lithium-ion
battery
Empty Wash Fill Dock
The serial number is on a sticker on the underside
of the robot.
Note:
