The CL 55 is fitted with magnetic safety system
which stops the motor as soon as the large hopper
or lid is opened, thus preventing any access to the
cutting tool while it is in motion.
As soon as the lid opens, the motor stops.
To restart your machine, simply relock the lid and
press the green switch.
When using the hopper equipped with a lever, the
motor is stopped as soon as the lever is removed
from the bowl. To start the machine again, you
should simply position the lever at the aligned with
the base of the bowl.
The single-phase CL 55 is fitted with a temperature
fuse which automatically stops the motor if the
machine is left on for too long or overloaded. If
this happens, allow the machine to cool completely
before restarting.
The hinge pin must be fitted in its position at the back
of the motor unit before the machine is switched on.
SAFETY
• WORKING HEIGHT
The CL 55 is mounted on a stainless-steel base,
which we advise you to place on a stable surface.
However, there is no recommended working height,
given that this appliance is designed to stand on the
floor.
• NOISE LEVEL
The equivalent continuous sound level when the CL 55
is operating on no-load is less than 70 dB (A).
• ELECTRICAL DATA
CL 55 three-phase bi-speed
Motor
Speed
(rpm)
Intensity
(amp.)
230 V/50Hz 375 4,8
240 V/50Hz 375 4,9
120 V/60Hz 450 9,5
220 V/60Hz 450 4,9
Motor
Speed
(rpm)
Intensity
(amp.)
400 V/50Hz 375/750 2,0/2,7
220 V/60Hz 450/900 3,8/5,3
380 V/60Hz 450/900 2,0/2,7
CL 55 single-phase
- Power shown on data plate.
STANDARDS
Consult the declaration of compliance on page 3.
The discs are extremely sharp.
Handle with care.
WARNING
Do not open the lid until the motor has
come to a complete stop.
Never tamper with the locking and safety
systems.
Never put a hand object in the bowl while
the machine is operating.
Never force the ingredients down with
your hands.
Do not overload the machine.
REMINDER
