2) Introducing the vegetables too
quickly can result in a logjam. If
this occurs, clear the blockage
using the crank supplied for that
purpose (all other means are strictly
prohibited).
The crank serves to clear the machine if it becomes
clogged up with bulky vegetables.
❶
With the motor unit
facing you, slot the
black or white ejection
tool onto the motor
shaft and check that it
is properly positioned at
the bottom of the bowl.
This hopper performs the same func tions as the
one described above with its straight tube. But it is
different in that it is equipped with a sloping tube
especially designed for slanted cutting.
No special tool is required to attach these hoppers
onto the disc.
• AUTOMATIC FEED-HEAD
This hopper is intended for
continuous cutting tasks.
It is ideal for slicing
delicate vegetables such as
mushrooms and tomatoes,
grating carrots, slicing
potatoes and cutting french
fries, to mention but a few of its uses.
This hopper is not suitable for certain specific tasks,
such as :
- slicing long vegetables (use the hole feed-heads).
- preparing bulky vegetables which are too big
to be fed into this hopper (use the pusher feed-
head).
Make sure that the agitator is in place, in order to
avoid blockages and variations in cutting quality.
It is vital that this tool be fitted each time the
automatic hopper is used.
Two types of tool are designed for the lever-type
hopper: :
1) The agitator, which guides the
vegetables (except for cabbage)
towards the blades.
2) The hollowing cutter used only
to prepare cabbage
A special tool for unlocking
the cabbage corer.
• HOLE FEED HEADS
4 TUBES FEED-HEAD
This feed-head is equipped
with 4 straight holes: 2
straight tubes of 50 mm
diameter and 2 straight
tubes of 70 mm diameter.
This hopper is designed
for the preparation of long
vegetables like carrots,
cucumbers,leeks, etc., or of fragile fruit and
vegetables such as tomatoes, bananas, etc.
STRAIGHT AND SLOPING TUBE HOPPER
This hopper consists of
two straight tubes with
a diameter of 75 mm
diameter, a 50 mm insert
and 2 pushers of 50 mm
and 70 mm. The insert
allows you to modify the
diameter of the tubes.
INSTALLING THE DISCS
AND TOOLS
Two ejection tools:
The CL 55 is supplied with two ejection tools. The
white ejector has been specially designed to cope
with cabbage. For all other vegetables, use the
black plastic ejector disc.
